Electra 1.0
Electra 1.0 is the 100% electric 48 Volt compact road sweeper, with 360 l (95.1 gal) removable DIN waste hopper and zero CO2 emissions.
Balanced and ergonomic, with extraordinary performance, quiet operation and extremely compact size, it guarantees runtime of up to nine hours and is the perfect solution for cleaning town centers, pedestrianized areas, cycle lanes, and more generally any small or medium-sized areas, both indoors and outdoors. Safe and intelligent, Electra 1.0 improves the lives of both operatives and residents.
Steering
The tried and tested electric steering system provides exceptional agility and maneuverability, as well as ease of steering and improved safety; combined with excellent directional stability, it allows the driver to concentrate fully on the task at hand without distractions or having to worry about maneuvers. Thanks to its two steered front wheels, which offer increased maneuverability, Electra 1.0 is able to efficiently clean any surface, from the narrowest alleyways to the largest squares.
Batteries and Runtime
Electra 1.0 can be equipped with different types of 48 Volt low voltage battery packs designed specifically for the device. The possibility to use different types of batteries (AGM and lead acid) allows the machine to be adapted to the specific working requirements and budget of each customer. Depending on the battery type chosen, runtime ranges from nine to ten hours, and is therefore able to cover an entire work shift. The tried and tested technology used minimizes the environmental footprint and offers high levels of recyclability, as well as high levels of safety thanks to the low voltage.
Charging and Regeneration
Electra 1.0 can be equipped with a wide variety of external single-phase and three-phase battery chargers with different voltages, power ratings and charging times to fully meet customer requirements. Electra 1.0 is also equipped with a regenerative braking system which allows the device’s runtime to be further extended.
Sweeping
The Electra 1.0 electric road sweeper is equipped with a suction waste collection system. Two independent counter-rotating brushes, positioned in front of the front axle, convey the waste towards the suction inlet and an innovative air filtration system with 99% filtration efficiency which traps fine powder down to PM 2.5, even when dry. During the work phase, the self-balancing nature of each component adapts to any road surface to ensure perfect operation at all times.
Waste Hopper
The RSU standard interchangeable 360 l (95.1 gal) or 240 l (63.4 gal) HDPE waste hopper is EN 840 (UNI 10571 and DIN 30740) compliant; it is extremely strong and completely watertight. Replacing the full hopper with an empty one requires no physical exertion by the operator. It is possible to install an optional 360 l (95.1 gal) waste hopper system with 1,400 mm (55.12 in) raised offloading incorporated, allowing the waste to be offloaded into bins and containers with ease and without any exertion. It allows the swept up waste to be easily offloaded into wheelie bins/dumpsters. The 100 l (26.42 gal) AISI 304 stainless steel clean water tank guarantees maximum runtime and use of the dust abatement system.
Safety and Driving Comfort
The ergonomic and soundproofed fiberglass cab of the Electra 1.0 sweeper offers a very high level of comfort to the operator along with a unique driving experience, thanks also to the damped four-wheel suspension. Equipped with an adjustable and anatomical shock-absorbing seat, it allows the operator to work in total comfort and safety with minimal vibration. The ergonomic controls located in the cab are intuitive and easy to use, allowing the operator to concentrate on their work without distractions. The panoramic LAMINATED anti-glare windscreen and fully glazed doors provide optimal visibility, however optional supplementary video cameras are available to provide an even wider view of the surrounding area. Safety is no less important either inside the cab, with seat belts and a Bluetooth radio, or outside with enhanced lighting of the sweeping area to ensure full visibility during night-time operation or in poor visibility.
Connectivity
Fleet monitoring and digitization via Tenax Link facilitates the work of both owners and operators. Tenax Link offers targeted services and support, with constant monitoring to minimize downtime and operating costs. The goal is to guarantee use of the sweepers at an optimum level by eliminating all operating inefficiencies.
Compact Dimensions
Its extremely compact size with reduced exterior dimensions and limited total mass allow Electra 1.0 to be used on any indoor or outdoor surface, making it extremely comfortable and maneuverable in urban environments.
